Description
When ordering raw materials, you can expect minor rust and oils that will need to be cleaned upon arrival to you.
Contents:
- (4) 5 Leaf slipper Spring for 7000 lb Axles
- (8) 7″ Long U-bolts
- (4) U-bolt Tie Plates for 1-3/4″ or 2″ Spring
- (16) 1/2″-20 Hex Nuts
- L=7″ A=3″ D=1/2″
- (2) 3-3/4″ tall front hangers
- (2) 3-3/8″ tall center hangers
- (2) 5-1/6″ tall rear hangers
- (2) 12″ long straight equalizers
- (8) 3-1/2″ long x 9/16″ diameter shackle bolts
- (8) 9/16″ diameter locknuts
- (2) 4-11/16″ long x 7/8″ diameter equalizer bolts
- (2) 7/8″ diameter castle nuts
- (2) 2-1/4″ long cotter pins
Features:
- Spring Specs: Number of leaves: 5, 2″ Wide, 26 5/8″ Long (from center eye to end of hook), 9/16″ Eye Diameter, Nylon Bushing, 3500 lb capacity each, Axle capacity: 7000 lbs.
- This kit has everything you need to mount your trailer’s 3″ round axle.
- Spring seats required for mounting axle to leaf spring sold separately.
- Will replace Suspension on Axle Brands: Dexter, AlKO, Hayes, Rockwell American, Quality Axles.
- This kit is for a Tandem axle 7K (14K total) setup
