Description
Progressive, kid-focused design. The Charger Youth 26 has kid-friendly geometry, high-quality suspension and gearing, and powerful disc brakes.
Spark a lifetime of exploring.
Charger Youth features three sizes, 20″, 24″ and 26″ wheels, for options on a low standover on a lightweight aluminum frame – modern features for the whole family. Head for local trails and urban pathways, cruise the campground, or commute to school in style.
Versatile and durable frame details.
Lightweight aluminum youth frame fits just right with custom tube shapes and optimized standover height, giving more control to young riders.
Built just for kids.
New sizes for youth riders who aren’t ready to step up to a frame with 27.5″ wheels. Each size features a low standover height with the ability to raise the seat as riders grow.
Plush, supportive suspension and gearing.
All Charger’s come with a lightweight, easy-adjust air spring suspension fork.
High-quality brakes, sized for kids.
Charger comes equipped with powerful hydraulic disc brakes so young riders can start learning to feather the brakes and stop exactly when they want to. Brakes have JR levers for smaller hands, providing more control.
Premium Shimano drivetrain.
The perfect gear range to keep young riders shifting smoothly, and a wide-range cassette to keep the ride rolling smoothly – both up the trail and down.
Limited Lifetime Warranty.
Charger Youth’s frame design, hardware and component decisions have been made specifically to keep it on the trail for longer. Accidents can happen, and when they do, our No Other Way Limited Lifetime Guarantee is our promise to get you back on the trail as soon as possible.
SPECIFICATIONS
| Frameset | |
| Frame | Aluminum, 9x135mm QR, 26″ |
| Fork | SR Suntour XCR 27.5″ 32 Air, Lock out / Rebound / Light Tune, 80mm, 9×100 QR |
| Drivetrain | |
| Rear Shifter | Shimano Cues SL-U4000, 9sp |
| Rear Derailleur | Shimano Cues RD-U4000, 9sp, GS |
| Crankset | Alloy 3pc, 152mm, 28T Narrow Wide |
| Bottom Bracket | Sealed bearing, ST 68mm |
| Cassette | Shimano Cues CS-LG300-9, 11-46T, 9sp |
| Chain | KMC Z9 |
| Brakes | |
| Front Brake | Tektro HD-M286, Resin Pads |
| Front Brake Rotor | Tektro, 160mm, 6-bolt |
| Rear Brake | Tektro HD-M286, Resin Pads |
| Rear Brake Rotor | Tektro, 160mm, 6-bolt |
| Brake Levers | Tektro HD-M286, Hydraulic 2-Finger Jr. Levers |
| Components | |
| Handlebar | 6061 Alloy DB 1.6mm, 720mm, 20mm rise |
| Stem | Alloy 45mm Length, 31.8mm Clamp |
| Seatpost | Norco Alloy 31.6mm, 250mm length |
| Headset | External Cup Ball Bearing, 1-1/8″ EC 34 |
| Headset Spacer | 1×10mm, 2×5mm |
| Saddle | Norco Jr XC, Steel Rail |
| Grips | Norco Youth, 115mm Length |
| Pedals | Jr. MTB Flat, 9/16″ |
| Seatpost Clamp | Norco Alloy Bolted, 34.9mm ID |
| Wheels | |
| Front Hub | Formula DC-1420, 9x100mm QR, 28h, 6-bolt |
| Rear Hub | Formula DC-1425, 10x135mm QR, HG, 38H, 6-bolt |
| Rims | Aluminum DW, 28h, 26″ MTB |
| Front Tire | CY Trail, 26×2.25″, Wire |
| Rear Tire | CY Trail, 26×2.25″, Wire |
| Spokes/Nipples | Stainless Steel w/Brass Nipples |
| Weight | |
| Weight | 12.36 kg (27.2 lbs) |
