Description
Brand: JE Pistons
Manufacturer’s Part Number: 242886
Part Type: Pistons
Product Line: JE Pistons 350/400 Standard Flat Top Pistons
Automotive Fittings Part Number: JEP-242886-8
UPC: 193564003522
Piston Rings Included: No
Bore (in.): 4.125 in.
Bore (mm): 104.775mm
Stroke: 4.000 in.
Engine Stroke Type: Stroked
Rod Length: 6.000 in.
Piston Style: Flat top, with four valve reliefs
Piston Material: Forged aluminum
Compression Height (in.): 1.000 in.
Piston Head Volume (cc): +5.00cc
Wrist Pin Style: Press-fit or floating
Wrist Pin Retainers Included: Yes
Wrist Pin Included: Yes
Pin Diameter (in.): 0.927 in.
Piston Ring Thickness: 1/16 in. x 1/16 in. x 3/16 in.
File Fit: No
Gapless: No
Remanufactured: No
Quantity: Sold as a set of 8.
Notes: Oil rail support included. 0.295 inch deep intake pocket.
Description:
These classic, race-winning 350/400 standard flat top JE Pistons work with most aftermarket 23 degree heads. They have extra-deep valve pockets and a low-friction skirt design. They are to be used with 1/16, 1/16, 3/16 or 1/16, 1/16, 3.0mm rings.
