Fox MY25 Steel Coil Spring – 700lb/in, 2.8-inch Diameter Replacement Part

Description

The black standard springs for FOX rear shocks are available in many different versions in terms of hardness, travel and overall length. Each of the extremely durable, powder-coated shock springs is marked with its spring rate and the total travel. According to the manufacturer, the basic rule for correct selection is that the stroke of the shock absorber should be less than the travel indicated on the steel spring itself.

• 700 lbs/in
• Spring travel: 2.8″ (71 mm)
• Inner diameter: 1.385″ (approx. 35 mm)

Compatible rear shocks:

• Metric: 230 x 57.5 mm / 230 x 60 mm / 230 x 62.5 mm / 230 x 65 mm
• Trunnion (Metric): 205 x 60 mm / 205 x 62.5 mm / 205 x 65 mm
• Imperial: 8.50″ x 2.50″ (216 x 63 mm)

(installation length x damper stroke)
