Description
Cannondale Topstone Carbon 1 AXS Gravel Bike
Always Game
Built for riders who embrace every detour, the Topstone Carbon 1 AXS is a capable, adventure-ready gravel bike that makes light work of whatever the trail throws at you.
Cannondale Topstone Carbon 1 AXS — Full Carbon Gravel Bike with SRAM Rival AXS XPLR and Reserve Carbon Wheels
The Topstone Carbon 1 AXS combines a lightweight full carbon frameset with Cannondale’s Kingpin rear suspension system to deliver a composed, comfortable ride over roots, rocks, and rough gravel. Proportional Response size-specific construction optimises stiffness and compliance for each frame size, and the downtube Stashport keeps supplies close on long days in the saddle. SRAM Rival AXS XPLR 13-speed wireless electronic shifting handles the drivetrain with smooth, effortless precision, and the 1x setup keeps things simple without sacrificing range. Reserve 40|44 GR carbon wheels on DT Swiss 370 hubs are built to thrive on rough terrain, and WTB Vulpine TCS Light 700x45c tubeless-ready tyres roll fast and grip confidently on loose surfaces. Easton EA70 AX flared handlebars and the Cannondale SAVE carbon seatpost add comfort and control on technical terrain, while the Cannondale Wheel Sensor feeds accurate speed, distance, and route data straight to the Cannondale App. Adventure never looked so good.
What It’s For
Gravel riding and racing, bikepacking, and going hard and long on dirt or pavement.
Highlights
- Lightweight full carbon frameset with Kingpin rear suspension, Proportional Response construction, and downtube Stashport storage
- SRAM Rival AXS XPLR 13-speed wireless electronic shifting for smooth, effortless 1x gravel performance
- Reserve 40|44 GR carbon wheels on DT Swiss 370 hubs with WTB Vulpine TCS Light 700x45c tubeless-ready tyres for fast, confident riding on rough terrain
- Cannondale SAVE carbon seatpost and Easton EA70 AX flared handlebars for comfort and control on technical terrain
- Cannondale Wheel Sensor for accurate speed, distance, and route data via the Cannondale App
Specifications
| Frameset | |
| Frame | Topstone Carbon, Kingpin suspension system, Proportional Response construction, downtube Stashport, internal cable routing, 12x142mm thru-axle, 27.2 dropper post ready, UDH, BSA 68mm threaded BB, flat mount disc, removable fender bridge, multiple gear/bottle mounts |
| Fork | Topstone Carbon, 1-1/8″ to 1-1/2″ steerer, 55mm OutFront offset, flat mount disc, internal routing, 12x100mm thru-axle, triple bottle/gear mounts, fender mounts |
| Headset | Acros IS52/40 ICR |
| Drivetrain | |
| Rear Derailleur | SRAM Rival AXS XPLR |
| Shifters | SRAM Rival AXS |
| Chain | SRAM Rival |
| Crankset | SRAM Rival DUB Wide, 40T |
| Cassette | SRAM Rival XPLR XG-1351, 10-46, 13-speed |
| Bottom Bracket | SRAM DUB BSA Road 68 Wide |
| Brakes | |
| Brakes | SRAM Rival hydraulic disc, 160/160mm PaceLine centerlock rotors |
| Brake Levers | SRAM Rival AXS hydraulic disc |
| Wheels | |
| Rims | Reserve 40|44 GR Carbon, Turbulent Aero Tech, 24h, tubeless ready |
| Spokes | Sapim CX-Ray Aero, straight pull |
| Hubs | (F) DT Swiss 370, 12x100mm centerlock / (R) DT Swiss 370 LN Ratchet System, 12x142mm centerlock |
| Tyres | WTB Vulpine TCS Light, 700x45c, tubeless ready |
| Components | |
| Handlebar | Easton EA70 AX, Alloy, 16 deg flare, 120mm drop: 400mm (47cm), 420mm (51-54cm), 440mm (56-61cm) |
| Stem | Cannondale C1 Conceal, Alloy, 31.8, -6°: 70mm (47-51cm), 80mm (54cm), 90mm (56-58cm), 100mm (61cm) |
| Grips | Cannondale KnurlCork, 2.7mm |
| Saddle | Fizik Terra Argo X5, S-Alloy rails |
| Seatpost | Cannondale SAVE Carbon, 27.2x350mm (47-58cm), 400mm (61cm) |
| Extras | |
| Extras | Large StashBag downtube storage bag, Reserve Fillmore tubeless valve stems, SRAM AXS charger |
